ISO Series

ISO flange components are vacuum components and fittings that conform to international standards established by the International Organization for Standardization (ISO). These flanges are designed for use in vacuum systems and are widely recognized for their compatibility and consistency in high and ultra-high vacuum applications.

Key features of ISO flange components include:

1. Standardized Dimensions: ISO flange components adhere to well-defined dimensions and specifications, ensuring compatibility and interchangeability between different manufacturers and systems. Common ISO flange sizes include ISO-K, ISO-F, and ISO-LF.

2. Materials: These flange components are typically constructed from high-quality materials such as stainless steel, aluminum, or other materials suited for vacuum environments.

3. Gasket Sealing: ISO flanges use a gasket to create a reliable seal between flange surfaces. Different types of gaskets, such as elastomer O-rings or metal gaskets, can be used to accommodate various vacuum levels and applications.

4. Bolted Connection: ISO flanges are typically connected using bolts or clamps to ensure a secure and leak-tight connection.

5. Compatibility: ISO flange components are compatible with a wide range of vacuum components, such as pumps, chambers, feedthroughs, and instrumentation, making them suitable for various vacuum system configurations.

6. High Vacuum Capability: ISO flange components are designed to maintain high and ultra-high vacuum levels, making them suitable for research, industry, and scientific applications.

7. Ease of Installation: ISO flange systems are known for their ease of assembly and disassembly, allowing for convenient maintenance and modifications in vacuum systems.

ISO flange components have become an industry standard for vacuum applications due to their versatility and reliability. They provide a consistent and well-established framework for creating and maintaining vacuum connections in a wide range of industrial and scientific settings.
